Waveshare IMX219-83 Stereo Camera, 8MP Binocular Camera Module, Depth Vision

This is a binocular camera module which features dual IMX219 cameras onboard, 8Megapixels of each camera. It is suitable for AI vision applications like depth vision and stereo vision.

The module supports NVIDIA Jetson Nano Developer Kit B01 version, Jetson Xavier NX Developer Kit, as well as Raspberry Pi CM3/CM3+ expansion boards like Compute Module IO Board Plus, Compute Module POE Board, etc.

Developer's Resources

• 8 Megapixels
• Sensor: IMX219
• Resolution: 3280 × 2464 (per camera)
• Lens specifications:
• CMOS size: 1/4inch
• Focal Length: 2.6mm
• Angle of View: 83/73/50 degree (diagonal/horizontal/vertical)
• Distortion: <1%
• Baseline Length: 60mm
• ICM20948:
• Accelerometer:
• Resolution: 16-bit
• Measuring Range (configurable): ±2, ±4, ±8, ±16g
• Operating Current: 68.9uA
• Gyroscope:
• Resolution: 16-bit
• Measuring Range (configurable): ±250, ±500, ±1000, ±2000°/sec
• Operating Current: 1.23mA
• Magnetometer:
• Resolution: 16-bit
• Measuring Range: ±4900μT
• Operating Current: 90uA
• Dimension: 24mm × 85mm

Package Includes :

1. IMX219-83 Stereo Camera x1
2. FPC 15pin 2PCS x1
3. FPC 15pin to 20pin 2PCS x1
4. PH2.0 4PIN wire x1
