INA240 4~80V Bidirectional Current Sense Amplifier Breakout 20V/V Gain

The 7Semi INA240 Breakout Board incorporates Texas Instruments' INA240 current-sense amplifier, providing a 20 V/V gain for precise bidirectional current measurement across a wide common-mode voltage range of -4V to 80V. It features enhanced PWM rejection, ensuring accurate readings in noisy environments, and is suitable for applications like motor drives and power management systems.

Datasheet

Features

Gain: INA240A1: 20 V/V – Amplify your current sensing precision.
Wide Common Mode Voltage Range (-4V to 80V): Measure currents accurately, even in systems operating below ground voltage.
Enhanced PWM Rejection: Obtain reliable measurements in environments with PWM signals, filtering out noise for greater accuracy.
High-Precision Voltage Output: Seamlessly integrate the INA240A1PW with your existing setup through its voltage output proportional to sensed current.
Compact & Convenient: The breakout board's design fits easily into your projects while offering hassle-free access to essential pins.
Versatile Applications: Ideal for diverse projects such as motor drives, solenoid control, battery management, and power monitoring.

Specifications

IC: INA240A1 Current Sense Amplifier
Gain: 20 V/V Fixed Gain
Common-Mode Voltage Range: -4V to +80V
Supply Voltage: 2.7V to 5.5V
Current Sensing: Bidirectional (Charge/Discharge Current Measurement)
Input Offset Voltage: ±25 µV (Max)
Gain Error: 0.2% (Max)
Bandwidth: 400 kHz
CMRR: Up to 132 dB
PWM Rejection: Enhanced PWM Rejection Technology
Quiescent Current: 2.4 mA (Max)
Operating Temperature: -40°C to +125°C
Output Type: Analog Voltage Output
Interface Pitch: 2.54 mm Header Compatible
Applications: Motor Control, Battery Monitoring, Power Supplies, Solar Systems, Current Monitoring, Industrial Automation
