L76K Multi-GNSS Module, Supports GPS, BDS, QZSS
₹​1,327.50
₹​1,125.00 + 18% GST
All Inclusive, Shipping Calculated at Checkout
Assured Cashback of ₹ 10
B2B GST Credit Available
Price in reward points: 979

L76K is a multi-satellite system (GPS, BeiDou, GLONASS, QZSS), multi-system joint positioning and single system independent positioning, supports AGNSS function, built-in low noise amplifier and surface acoustic filter, can provide users with fast and accurate, GNSS module with high-performance positioning experience.

This module supports Raspberry Pi, STM32, Arduino, Raspberry Pi Pico and ESP32 control demo.


Features

  • Supports Multi-GNSS systems: GPS, BeiDou (BDS), GLONASS and QZSS
  • Built-in Low-Noise Amplifier (LNA) for improved reception sensitivity
  • Built-in SAW Filter for enhanced noise reduction performance
  • Support AGNSS
  • Support 1PPS
  • UART communication baudrate: 4800~115200bps (9600bps by default)
  • Onboard rechargeable Li battery MS621FE, for preserving ephemeris information and hot starts
  • 2x LEDs for indicating the module working status
  • Comes with online development resources and manual (examples for Raspberry Pi/Jetson Nano/Arduino/STM32)


Resources

User Manual


Onboard Peripherals


PINOUT DEFINITION
VCCPower supply (3.3V/5V)
TXConnect to MCU.RX (Signal direction: TX >> MCU.RX)
RXConnect to MCU.TX (Signal direction: MCU.TX >> RX)
PPSGPS status indicator
