Ebyte MA01-AXCX4020 4DI + 2DO RS485 ModBus RTU I/O Network Module with Serial Port

MA01-AXCX4020 supports the acquisition of 4-channel sensor switch input (DI), which is converted to serial port (RS485) and data is transmitted to configuration software or PLC. The serial port I/O networking module (also known as "remote IO") that controls 2 relay switch outputs (DO) by issuing commands through the serial port to realize remote acquisition and control functions.

Datasheet

Features

Support ModBus RTU protocol
Support various configuration software/PLC/touch screen
RS485 acquisition and control IO
DC 8～28V power supply
4-way switch input DI (dry node)
4-channel switch output DO (relay)
Switch input (DI) supports counting function
The switch input (DI) supports rising edge, falling edge, and level trigger mode
Switch output (DO) supports level mode, pulse mode, follow mode
The output port is designed with arc extinguishing protection
Communication baud rate 1200～115200 (default 9600), support custom setting
Supports 1～247 slave stations, 5-digit DIP switch can set 1～31 address code, more than 31 can be set bysoftware

Specifications

Digital input: 4
Digital output: 2
Operating Voltage: 8~28V (DC)
Communication Interface: RS232/RS485
Protocol Modbus: RTU
baud rate: 1200~115200 bps (default 9600 bps)
Working temperature and humidity: -40℃ ~ +85℃, 5%~95%RH, no condensation
Storage temperature and humidity: -60℃ ~ +125℃, 5%~95%RH, no condensation
Installation method: Rail installation or positioning hole installation
Dimensions: 50*80mm
