MaxLinear SP485EEN-L/TR transceiver 4.75V~5.25V 10Mbps 1/1 SOIC-8

MaxLinear SP485EEN-L/TR transceiver 4.75V~5.25V 10Mbps 1/1 SOIC-8
Max Linear
MaxLinear SP485EEN-L/TR transceiver 4.75V~5.25V 10Mbps 1/1 SOIC-8
₹​34.00 + 18% GST
All Inclusive, Shipping Calculated at Checkout

B2B GST Credit Available

The SP481E and SP485E are a family of half-duplex transceivers that meet the specifications of RS-485 and RS-422 serial protocols with enhanced ESD performance. The ESD tolerance has been improved on these devices to over ±15kV for both Human Body Model and IEC61000-4-2 Air Discharge Method. These devices are pin-to-pin compatible with MaxLinear’s SP481 and SP485 devices as well as popular industry standards. As with the original versions, the SP481E and SP485E feature Maxlinear’s BiCMOS design allowing low power operation without sacrificing performance. The SP481E and SP485E meet the requirements of the RS-485 and RS-422 protocols up to 10Mbps under load. The SP481E is equipped with a low power shutdown mode.

The RS-485 standard is ideal for multi-drop applications and for long-distance interfaces. RS-485 allows up to 32 drivers and 32 receivers to be connected to a data bus, making it an ideal choice for multi-drop applications. Since the cabling can be as long as 4,000 feet, RS-485 transceivers are equipped with a wide (-7V to 12V) common mode range to accommodate ground potential differences. Because RS-485 is a differential interface, data is virtually immune to noise in the transmission line.


Technical Datasheet
