Name: ME31-AXAX4040 4DI + 4DO Modbus Gateway IoT Ethernet I/O Networking Module
Brand: Ebyte
SKU: 05698
Price: 3741.00 INR
Availability: OutOfStock

ME31-AXAX4040 4DI + 4DO Modbus Gateway IoT Ethernet I/O Networking Module

Ebyte

ME31-AXAX4040 4DI + 4DO Modbus Gateway IoT Ethernet I/O Networking Module

This product qualifies for Free Surface Shipping !

All orders with value above 1999+GST are eligible for free delivery in Surface mode. (Not applicable for B2B offline orders)

Based on 0 reviews. - Write a review

₹3,741.00

₹3,170.34 + 18% GST

All Inclusive, Shipping Calculated at Checkout

Assured Cashback of ₹ 32
B2B GST Credit Available

Price in reward points: 3170

Stock: 0 in Stock
SKU: 05698
Delivery Time
Bulk & B2B RFQ

Buy Now NOTIFY WHEN AVAILABLE

Plan to Buy Later ? Add to Wish List

ME31-AXAX4040 4DI + 4DO Modbus Gateway IoT Ethernet I/O Networking Module

ME31- AXAX4040 is equipped with 4-way A-type relay output and 4 -way dry contact input detection , supports Modbus TCP protocol or Modbus RTU protocol for acquisition control, and the device can also be used as a simple Modbus gateway (automatically convert non-local Modbus The command of the address is sent through the serial port/network port) of the network I/O networking module .

User Manual

Features

Support standard Mod b us RTU protocol and Mod b us TCP protocol ;
Support various configuration software/PLC/touch screen;
RS485 acquisition control I/O;
R J45 acquisition and control I /O , support 4- way host access;
4- way switch input DI (dry node);
4-way switch output DO ( Form A relay);
Switch output (DO) supports level mode, pulse mode , follow mode, reverse follow mode, trigger flipmode;
Support custom Modbus address setting;
Support 8 common baud rate configurations;
Support DHCP and static IP ;
Support DNS function, domain name resolution;
Support Modbus gateway function;
Support input and output linkage;

Specifications

Nominal Voltage : DC 8～28V
Power indicator : Blue LED indication
Communication Interface : RJ45, RS485
Baud rate : 9600bps (customizable)
Protocol : Modbus TCP, Modbus RTU
Device address : The default value is 1 and can be changed
Number of DI : 4
DI Input type : Default passive switch input
Input instructions : Green LED indicates
Number of DO : 4
DO output type : Single pole single throw type
Product size : 121mm * 72mm * 34mm(Length*width*height)
Installation method : Rail installation
