Name: Mean Well LRS-35-24 24V 1.5A 36W Switching Power Supply (SMPS) - Single Output
Brand: Mean Well
SKU: 07630
Price: 899.00 INR
Availability: InStock

Mean Well LRS-35-24 24V 1.5A 36W Switching Power Supply (SMPS) - Single Output

Mean Well

Mean Well LRS-35-24 24V 1.5A 36W Switching Power Supply (SMPS) - Single Output

Based on 0 reviews. - Write a review

₹899.00

₹761.86 + 18% GST

All Inclusive, Shipping Calculated at Checkout

Assured Cashback of ₹ 8
B2B GST Credit Available

Price in reward points: 761

Stock: 3 in Stock
SKU: 07630
Delivery Time
Bulk & B2B RFQ

Add to Cart

Buy Now

Plan to Buy Later ? Add to Wish List

Mean Well LRS-35-24 24V 1.5A 36W Switching Power Supply (SMPS) - Single Output

The Mean Well LRS-35-24 is a compact and reliable 36W single-output switching power supply (SMPS) designed to deliver a stable 24V DC output at 1.5A. Built with a low-profile design, it is ideal for space-constrained applications such as industrial automation, LED lighting, and electronic equipment.

Engineered for high efficiency and long-term performance, the LRS-35-24 features universal AC input capability, allowing it to operate across a wide voltage range. It incorporates robust protection mechanisms including short circuit, overload, and overvoltage protection to ensure safe and stable operation. The power supply uses convection air cooling, eliminating the need for a fan and ensuring silent performance.

With its durable metal enclosure, easy screw terminal connections, and compliance with international safety standards, the Mean Well LRS-35-24 is a dependable choice for both commercial and industrial power supply needs.

Datasheet

Features

Compact and low-profile design (30mm height)
Universal AC input range: 85–264V AC / 120–373V DC
Stable 24V DC single output at 1.5A
High efficiency up to ~88%
Built-in protections: short circuit, overload, overvoltage
Fanless design with natural air convection cooling
Durable metal enclosure for enhanced heat dissipation
LED indicator for power-on status
Withstand 300VAC surge input for 5 seconds
Low no-load power consumption
Compliant with international safety standards

Specifications

Model: LRS-35-24
Output Voltage: 24V DC
Output Current: 1.5A
Rated Power: 36W
Input Voltage Range: 85–264V AC / 120–373V DC
Frequency Range: 47–63Hz
Efficiency: Up to 88%
Output Voltage Adjustment Range: 21.6V – 28.8V
Overload Protection: 105%–150% (hiccup mode, auto recovery)
Overvoltage Protection: 28.8V – 33.6V
Operating Temperature: -30°C to +70°C
Storage Temperature: -40°C to +85°C
Cooling Method: Free air convection
Mounting Type: Chassis mount
Dimensions: Approx. 99 x 82 x 30 mm
Weight: Approx. 230g

Package Includes

1x Mean Well LRS-35-24 24V 1.5A 36W Switching Power Supply (SMPS) - Single Output
