Nano Board with Header - Micro USB Port - Based On ATmega328p-AU Chip
Nano Board is fully as compatible as Arduino Nano. It is based on the ATmega328p-AU from Atmel, the SMD version of one used in Arduino Uno. The advantage of this module is that is very small in size as compared to Arduino Uno. It has an integrated USB and is breadboard-friendly. It does not have any power jack but still 9V DC can be provided to Vin pin.
Nano Board can be said to be a smaller version of Arduino Uno, as it uses the same MCU with a smaller package. It also provides the same functions as provided by Arduino Uno. Apart from that, it has 8 analog input pins instead of 6 analog inputs in Arduino Uno. It also has a pinout for the programmer to be connected to the board directly, in case USB is not used for programming. It also has 1 x UART, 1 x SPI, and 1 x I2C peripherals.
The Nano has 2 digital interrupt pins, and almost all pins can be used for pin change interrupt. Any pin can wake up MCU on an interrupt from sleep mode. It works on a 16 MHz frequency.
Features
- Pin to Pin is compatible with Arduino Nano.
- Nano Board is compatible with Arduino IDE software.
- Manual Reset switch is available.
- Power, TX, RX LED for indication.
Specifications
- Micro controller: ATMega328p-AU
- Input Voltage: 7 V to 9 V
- Operating Voltage: 5 V
- Flash Memory: 32 KB (out of which 2 KB used by bootloader)
- SRAM: 2 KB
- EEPROM: 1 KB
- Clock Speed: 16 Mhz
- Analog Input Pins: 8
- Digital I/O pins: 14
- PWM pins: 6
- Max Current Per I/O pins: 40 mA
- Onboard 5V Regulator
Applications
- Samples of electronic systems & products
- Automation
- Several DIY projects
- Control Systems
- Embedded Systems
- Robotics
- Instrumentation
Package Includes
- 1x Nano Board with Header
