PCIe FFC Connector To Standard PCIe x1 Slot Adapter Board (C) For Raspberry Pi 5, Compatible With PCIe x1, x4, x8, And x16 Interface Devices

PCIe FFC Connector To Standard PCIe x1 Slot Adapter Board (C) For Raspberry Pi 5, Compatible With PCIe x1, x4, x8, And x16 Interface Devices

The PCIe FFC Connector to Standard PCIe x1 Slot Adapter Board (C) for Raspberry Pi 5 is a versatile expansion solution designed to enable PCIe connectivity for your Raspberry Pi 5. This adapter allows you to connect standard PCIe x1, x4, x8, and x16 interface devices via an FFC (Flexible Flat Cable) connection, providing seamless integration with a wide range of peripherals such as NVMe SSDs, network cards, and other PCIe expansion cards.

User Manual / Datasheet / Example Codes Etc.

Features

• PCIe x1 Slot Interface: Converts the Pi’s PCIe FFC connection to a standard PCIe x1 slot.
• Broad Device Support: Compatible with PCIe x1, x4, x8, and x16 interface devices (operating at x1 bandwidth).
• Flexible Connection: Uses an FFC cable for a compact and flexible setup, ideal for space-constrained projects.
• Plug-and-Play Design: Simplifies installation with no additional power required for most low-power PCIe devices.

Package Includes

• PCIe TO PCIe x1 Board (C) x1
• Transparent acrylic mounting plate x1
• PCIe-Cable-50mm x1
• PH2.0 3PIN cable x1
• Screws pack x1
• 12V 2A power supply x1

PCIe Connection

How to install

Dimensions
