PoE Ethernet / USB HUB BOX for Raspberry Pi Zero Series, 3x USB 2.0, 802.3af-Compliant

PoE Ethernet / USB HUB BOX for Raspberry Pi Zero Series, 3x USB 2.0, 802.3af-Compliant
PoE Ethernet / USB HUB BOX for Raspberry Pi Zero Series, 3x USB 2.0, 802.3af-Compliant
PoE Ethernet / USB HUB BOX for Raspberry Pi Zero Series, 3x USB 2.0, 802.3af-Compliant
PoE Ethernet / USB HUB BOX for Raspberry Pi Zero Series, 3x USB 2.0, 802.3af-Compliant
PoE Ethernet / USB HUB BOX for Raspberry Pi Zero Series, 3x USB 2.0, 802.3af-Compliant
PoE Ethernet / USB HUB BOX for Raspberry Pi Zero Series, 3x USB 2.0, 802.3af-Compliant
PoE Ethernet / USB HUB BOX for Raspberry Pi Zero Series, 3x USB 2.0, 802.3af-Compliant
PoE Ethernet / USB HUB BOX for Raspberry Pi Zero Series, 3x USB 2.0, 802.3af-Compliant
WaveShare Electronics
PoE Ethernet / USB HUB BOX for Raspberry Pi Zero Series, 3x USB 2.0, 802.3af-Compliant
₹​2,199.00
₹​1,863.56 + 18% GST
All Inclusive, Shipping Calculated at Checkout
Assured Cashback of ₹ 19
B2B GST Credit Available
Price in reward points: 1864

The PoE-ETH-USB-HUB-BOX is a HUB kit with PoE/ETH/USB HUB HAT inside. It is tailored for the Raspberry Pi Zero series, small in size, each cut-out of the case is exactly aligned with the connector. The case adopts a classic Raspberry Pi red/white color combination, with the quality dull polish surface, effectively keeping the Zero away from dust. By using this small HUB BOX and some proper 802.3af-compliant power sourcing equipment, it is possible to provide both network connection and power supply for your Raspberry Pi Zero in only one Ethernet cable, along with 3x extended USB ports.

  • Designed for Raspberry Pi Zero, compatible with Zero series boards
  • Incorporates RTL8152B Ethernet chip, with 10M / 100M auto-negotiation RJ45 port
  • PoE (Power over Ethernet) feature, 802.3af-compliant
  • Fully isolated SMPS (Switch Mode Power Supply)
  • 3x extended USB ports, compatible with USB 2.0 / 1.1
  • Angle rounded design, smooth hand feeling, "simple snap" case lid
  • Quality ABS material, dull polish surface, anti-fingerprint
  • Comes with two different lids, changing as you like


Additional Resources

Information and Datasheet




Compatible with Raspberry Pi Zero Series

Specialized Pogo Pin Connection, Dedicated Cut-Outs For Zero Series, Plug-And-Play


Assembly Guide:



FAQ

1. Why doesn't Raspberry pi recognize USB devices?

Please connect the USB HUT interface to the PC by USB cable to check if the HUB can be recognized. If the HUB can be recognized by PC but not the Pi, please check if you have connected the USB connector tightly. And if you have set the USB port of Pi zero for networking, it cannot be used with the USB HUB either.

2. Does the KIT includes Raspberry Pi zero Board?

Raspberry Pi boards are not shipped with the KIT. The KIT contents are:

  1. PoE/ETH/USB HUB HAT kit x1
  2. ABS case x1
  3. Rubber feet 4PCS x1
  4. Screws pack x1
