[PREORDER] Radxa X4 8GB LPDDR5 RAM 64GB eMMC Single Board Computer - Based On Intel N100 Quad-Core Processor - Wi-Fi 6 & Bluetooth 5.2

Radxa X4 8GB LPDDR5 RAM 64GB eMMC Single Board Computer - Based On Intel N100 Quad-Core Processor - Wi-Fi 6 & Bluetooth 5.2

The Radxa X4 is powered by the Intel N100 processor, making it a high‑performance, cost‑ effective single board computer. It aims to deliver exceptional computing power and versatility.

The RADXA X4 is a powerful and versatile single-board computer (SBC) designed to cater to both enthusiasts and professionals. Equipped with a quad-core processor, ample RAM, and extensive connectivity options, the RADXA X4 delivers exceptional performance for a wide range of applications, from DIY projects to advanced computing tasks. Its compact form factor and robust hardware make it an ideal choice for developers, makers, and anyone looking to explore the possibilities of SBC technology.

Datasheet

Specifications

• CPU: Intel® Processor N100 (Alder Lake-N)
• Total Cores: 4
• Total Threads: 4
• Max Turbo Frequency: 3.40 GHz
• Cache: 6 MB Intel® Smart Cache
• Intel® Gaussian & Neural Accelerator 3.0
• Intel® Image Processing Unit 6.0

• Support for Intel® Virtualization Technology

• GPU
• Intel® UHD Graphics
• Graphics Max Dynamic Frequency: 750 MHz
• DirectX Support: 12.1

• OpenGL Support: 4.6

• OpenCL Support: 3.0

• RAM
• 8GB
• LPDDR5 RAM
• Maximum Frequency of 4800 MT/s

• Storage
• 64GB eMMC
• SPI Flash for BIOS
• 1x M.2 M Key Connector with PCIe 3.0 4-lane for M.2 2230 NVMe SSD

• Wireless Connectivity
• IEEE 802.11 a/b/g/n/ac (WiFi 6) and Bluetooth 5.2 with BLE


• USB
• 1x USB 2.0 HOST Type A Port
• 3x USB 3.0 HOST Type A Ports

• Connectivity
• 1x RTC Battery Socket
• 1x 2-Pin Fan Header
• 1x 2-Pin Power Input Header
• 40-Pin Color GPIO Header

• Button
• 1x Power Button is used for powering on and off
• 1x BOOTSEL Button is used to put the RP2040 into USB mass storage mode for firmware upload.

• Software
• Windows 10 / 11
• Debian / Ubuntu Linux support

• Audio: 1x Headphone Jack with Microphone Input
• Ethernet: 1x 2.5G Ethernet Port with PoE Support(Additional PoE HAT Required)
• Display: Dual Display Outputs via Two Micro HDMI up to 4Kp60
• Dimension: 85 mm x 56 mm

Interfaces

M.2 M Key Connector with PCIe 3.0 4-lane

Support for Storage Expansion and OS Boot
