Radxa Rock 3 Model C 2GB single board computer Module Rockchip RK3566
The ROCK 3 Model C (ROCK 3C) is a dependable single board computer based on the powerful Rockchip RK3566 SoC in an ultra-small form factor. Despite its compact size, it’s packed with remarkable features, including Quad core Armv8.2‑A Cortex®‑A55 CPU, Arm Mali G52 GPU, Wireless support including WiFi 5, HDMI 2.0 port supporting displays up to 1080p resolution, multiple connectivity and storage possibilities, and it’s compatible with a wide range of software operating systems Whether you’re an engineer, an IoT enthusiast, or a hobbyist looking to create ground-breaking applications we’re certain that you’ll be you blown away by the ROCK 3C. This impressive little board is a reliable and extremely capable platform for bringing your ideas to life.
- ROCK 3C SBC based on the powerful Rockchip RK3566 SoC
- Quad core Armv8.2‑A Cortex®‑A55 CPU and Arm Mali™ G52 GPU
- Wireless support including WiFi 5 and Bluetooth 5.0
- 32-bit LPDDR4 2GB RAM and eMMC socket
- HDMI® 2.0 port supporting display up to 1080p resolution
- M.2 M‑Key 2230 connector with PCIe 2.1 1‑lane and SATA 3.0 combo interfaces, providing high-speed storage access.
- Ultra-small form factor packed with remarkable features
Interface
- 802.11 b/g/n/ac Wireless LAN supporting WiFi 5
- BT 5.0
- 1x HDMI 2.0 port supporting displays up to 1080p resolution
- 1x SD Card slot
- 3x USB2 HOST ports – The upper middle port can be used as USB2 OTG/HOST port
- 1x USB3 HOST port
- 1x Gigabit Ethernet port – supports PoE with add‑on PoE HAT
- 1x M.2 M‑Key connector for NVMe SSD or SATA SSD
- 1x camera port supporting 2‑lane MIPI CSI
- 1x display port supporting 2‑lane MIPI DSI
- 3.5mm jack with microphone. The HD codec supports up to 24‑bit/96KHz audio
- 40x user GPIO supporting various interface options: up to 5 x UART, 1 x SPI bus, up to 2 x I2C bus, 1 x PCM/I2S, up to 6 x PWM, up to 28 x GPIO, 2 x 5V DC power in, 2 x 3.3V power pin
Technical Specifiations
| SoC CPU GPU NPU | RK3566 Quad-core Cortex-A55, frequency 1.6Ghz Mali G52 | |
|---|---|---|
| Memory | 1/2/4/8GB LPDDR4 2112MT/s | |
| Storage | eMMC μSD card (μSD slot supports up to 128 GB μSD card) M.2 2230 SSD (M.2 connector supports up to 1TB M2 NVME SSD) | |
| Display | HDMI 2.0 up to 1920x1080 60p MIPI DSI 2 lanes via FPC connector HDMI and MIPI DSI can not work at the same time | |
| Audio | 3.5mm jack with mic HD codec that supports up to 24-bit/96KHz audio. | |
| Camera | MIPI CSI 2 lanes via FPC connector, support up to 800 MP camera. | |
| Wireless | 802.11 ac WiFi 5/ BT 5 | |
| USB | USB 2.0 OTG X1(middle upper one), hardware switch for host/device switch USB 3.0 HOST X1 USB 2.0 HOST X2 | |
| Ethernet | GbE LAN with Power over Ethernet (PoE) support additional HAT is required for powering from PoE | |
| IO | 40-pin expansion header 5 x UART 1 x SPI bus 2 x I2C bus 6 x PWM 1 x ADC 6 x GPIO 2 x 5V DC power in 1 x 3.3V DC power in | |
| Others | RTC RTC battery connector for time backup(optional) | |
| Power | USB type C 5V, 5V/3A is suggested when using without SSD, 5V/5A is suggested when using with SSD. | |
| Size | 85mm x 56mm | |
