SC09 Servo - 2.3kg Serial Bus Servo, Two-way Feedback, Servo/Motor Mode Switchable, Compact Size, 300° Rotation Angle

SC09 Servo is a mini and compact dual-shaft serial bus servo, which can control within a range of 300° and can be programmed to switch to continuous rotation motor/stepper motor mode.There is an interface on the servo, which can be used in series to control 253 bus servos at the same time and each servo can get its current angle, load, voltage, mode, and other information. It is suitable for the robotic arm, hexapod robot, a humanoid robot, wheeled robot, and other robotic projects that require feedback on servo angle and load.

User Manual / Datasheet / Example codes Etc.

Features

Can be used in series to control up to 253 servos simultaneously (assuming adequate power supply) and obtain feedback from each servo.
Wide voltage input 4.8-8.4V.
Locked-rotor torque up to 2.3kg.cm@6V.
High precision, angle control accuracy up to 300°/1024.
Programmable operating mode: servo mode angle control/motor mode with continuous rotation.

Specifications

Input voltage VIN: 4.8-8.4V
Mechanism limit angle: no limit
Rotation angle: 300° (0~1024)
Baud rate: 38400bps~1Mbps
Gear type: high-precision metal gear
No-load speed: 0.1sec/60° (100RPM)@6V
Position sensor resolution: 0.293° (300°/1024)
ID range: 0-253
Feedback information: Position, Load, Speed, Input Voltage
No-load current: 150mA@6V
Locked-rotor current: 1.0A
Dimensions: 23.2×12.0×25.5mm

Package Includes

UART Serial Bus Control

Allows Controlling Up To 253 Serial Bus Servos At The Same Time

300° Rotation Angle

Allows Angular Control Within The Range Of 300° In Servo Mode

Open Source Control Program

Dimensions
