LILYGO T-Embed CC1101 + ESP32-S3 + PN532 NFC/RFID Wireless Transceiver Module With 1.9inch IPS LCD Display

LILYGO launched the T-Embed CC1101, built around the ESP32-S3 Dual-core LX7. It supports Wi-Fi, BLE 5, and Sub-GHz wireless communication, targeting remote and low-power IoT projects.

The ESP32-S3 microcontroller is paired with 16MB of Flash memory and 8MB of PSRAM. The CC1101 chip operates across frequency bands of 300-348 MHz, 387-464 MHz, and 779-928 MHz, with a communication range of up to 50 meters.

The board features a 1.9-inch ST7789V IPS color TFT LCD with a resolution of 320 x 170 pixels, interfaced via SPI with the ST7789V driver chip.

Additionally, the board is equipped with an infrared transmitter and receiver, a built-in microphone, and a PN532 NFC/RFID transceiver for contactless communication at 13.56 MHz.

Supporting both USB and Li-Po battery power, the board includes an onboard 1300mAh Li-Po battery, allowing independent operation for prolonged periods in remote sensor applications.

It is also compatible with popular development platforms like Arduino IDE and ESP-IDF, offering flexibility for IoT, wireless communication, or sensor-based projects.

User Manual / Datasheet / Example Codes Etc.

Specifications

MCU: ESP32-S3 Dual-core LX7 microprocessor
Flash: 16MB
Programming Platform: Arduino-ide, ESP-IDF
RSRAM: 8MB
Onboard functions: Reset + Boot Button , IR Transmit & Receive
Bat voltage detection: IO04
Wireless: Wi-Fi 802.11 b/g/n & BLE 5

1.9 inch ST7789V IPS color TFT LCD

Interface: SPI
Drive Chip: ST7789V
Resolution: 170(H)RGB x 320(V)

Pin Diagram
