Ex Gst ₹29.66₹849.60
All Inclusive, Shipping Calculated at Checkout
B2B GST Credit Available
20 or more ₹706.82
- Stock: 0 in Stock
- SKU: 02055
- Delivery Time
- Bulk & B2B RFQ
Wemos UNO + WiFi - ATmega328p + ESP8266 8Mb Flash - CH340G USB to TTL - NodeMCU
The perfect low cost IoT board with onboard ESP8266 + 8Mb flash, Chip antenna and direct interface with ATmega328p. Programmable (both Arduino + ESP8266) using CH340G based USB to TTL interface which can also be used as a generic com port. Ideal solution for Network connected embedded computing applications..
DIP Switch Configuration :
Connection | DIP | ||||||
1 | 2 | 3 | 4 | 5 | 6 | 7 | |
ATmega328<->ESP8266 | ON | ON | OFF | OFF | OFF | OFF | OFF |
USB <->ATmega328 | OFF | OFF | ON | ON | OFF | OFF | OFF |
USB<->ESP8266 (Update firmware or sketch) | OFF | OFF | OFF | OFF | ON | ON | ON |
USB<->ESP8266 (communication) | OFF | OFF | OFF | OFF | ON | ON | OFF |
All independent | OFF | OFF | OFF | OFF | OFF | OFF | OFF |
Getting started Tutorial -
https://github.com/LintangWisesa/RobotDyn_UnoWiFi_Favoriot
Package Includes - 1x UNO + WiFi Board (As shown in the product picture)
