USR-DR132 RS232 to Ethernet Converter Serial Device Server - Support Modbus RTU & TCP Protocol - Din Rail Mount
₹​1,652.00
₹​1,400.00 + 18% GST
All Inclusive, Shipping Calculated at Checkout
Assured Cashback of ₹ 14
B2B GST Credit Available
Price in reward points: 1400

USR-DR132 RS232 to Ethernet Converter Serial Device Server - Support Modbus RTU & TCP Protocol - Din Rail Mount - Industrial Grade  - Lipstick Size Serial Server Device

USR-DR132 is an ultra-small DIN rail mounting industrial-grade serial device server launched by PUSR. It can realize two-way fast data transmission between RS232 and RJ45 Ethernet port. It integrates TCP/IP protocol stack internally and Modbus gateway function. It can be directly integrated into industry scenarios, thus quickly completing business framework construction and saving human resources investment.


Resource


Features

  • Equipped with deeply optimized TCP/IP protocol stack. It has low latency and strong scalability, stable and reliable.
  • 1.5KV built-in network Magnetic Isolation.
  • Wide baud rate: 600~230.4 Kbps, multiple parity bit: NONE, Odd, Even
  • Supports Modbus RTU to Modbus TCP protocol conversion and multi-host polling.
  • Supports keepalive mechanism to quickly detect the dead connections and reconnect.
  • Supports hardware and software watchdog, automatically restarts when the device goes down.
  • 10/100Mbps Ethernet port and support Auto MDI/MDIX.
  • Supports a wide industrial operating temperature, -25℃~75℃.
  • Versatile operation modes: TCP Server, TCP Client, UDP, HTTP client.
  • Support virtual COM, COM Port Redirector USR-VCOM (windows).
  • Easy to config: built-in webpage and AT command to set parameters




“Lipstick” Size Serial Server Device



Serial to Ethernet,

Bidirectional Transparent Data Transmission


Support Modbus Gateway



Multiple User Scenarios
