1 port RS232 to Ethernet converters USR-TCP232-302 can transmit data transparently between TCP/IP and RS232. RS232 to IP Converters USR-TCP232-302 are widespread required in industrial automation. Simple configuration and easy to use.
- Single RS232 to Ethernet converters
- Cost-effective
- RS232 port
- Power supply: DC 4.75-7V
- Compact, Light Weight
- Supports TCP server/client, UDP server/client
- Virtual COM
Resources:
Features:
Processor | TI CORTEX M0 |
Port Number | Ethernet - 1 (RJ45) , Serial Port - 1 (RS232) |
| Virtual Serial | Windows 2000 or Higher (32Bit/64Bit) |
| Configuration | Computer Setup Software, Serial Command, BuiltIn Webpage |
| Size | 71 x 60 x 25 (in mm) |
| Operating Temperature | -25°C ~ 75°C |
| Input Voltage | 4.75V to 7V DC |
| Working Current | 150mA @ 5V |
| Accessory | 5V 1A Power Supply |
| Certificate | CE/FCC/RoHS |
Work mode TCP Server RS232 to Ethernet converters USR-TCP232-302 monitors the set port and waits for a TCP client connection.
Data from the serial device will transmit to all successfully-connected TCP clients.
TCP client mode RS232 to Ethernet converters USR-TCP232-302 will initiate TCP connection to the destination IP address that is configured by the user and USR-TCP232-302 will continuously try to reconnect if establishing TCP connection unsuccessfully.
If the USR-TCP232-302 establishes a TCP connection to TCP Server successfully, it can realize bidirectional data transparent transmission between TCP Server and the serial device.
UDP mode
RS232 to Ethernet converters USR-TCP232-302 will transmit serial data from serial device to target network device
by UDP connection. USR-TCP232-302 will listen to the port and transmit all received data to the serial device.
HTTPd Client
RS232 to Ethernet converters USR-TCP232-302 supports HTTPS Client mode which can transmit serial data to the HTTPS server in HTTPS format(GET/POST).
Synchronous Baud Rate
Dynamically change baud rate, data bit, check bit and stop bit of serial device server via network command.
Identity packet function
When RS232 to Ethernet converter USR-TCP232-302 works as TCP Client, it can send identity packet to TCP server
which can be identified. Identity packets can be IMEI code, ICCID code, and user-editable identity packet.
Serial & Network Heartbeat Packet
RS232 to Ethernet converters USR-TCP232-302 maintains the normal connection with the server by sending heartbeat packets regularly.
Applications:
Connect RS232 to Ethernet converters USR-TCP232-302 to barrier gate and they can realize
remote control of barrier gate by Ethernet in the control center.
[ Traffic Lights Management System ]Connect RS232 to Ethernet converter USR-TCP232-302 and it can realize traffic data acquisition and processing
by Ethernet in the control center. It can also provide an accurate quantitative basis for traffic dispatch
management and urban transport planning Can implement the optimum control for transportation phenomena
such as traffic jams, traffic accidents, traffic capacity from a regional or global perspective.
