Ebyte E75-2G4M10S JN5169 10dBm 500M 2.4GHz Zigbee Wireless Module

E75-2G4M10S designed by Chengdu Ebyte is a high-performance and low-consumption ZigBee wireless transceiver module, which is based on NXP JN5169. It provides a complete application integration scheme at ISM(2.4-2.5GHz) based on IEEE802.15.4. It supports protocols like FastZigBee, ZNET, JenNet-IP, ZigBee-PRO, RF4CE and etc.

Datasheet

Features

Communication distance tested is up to 500m in ideal condition
Maximum transmitting power of 10mW, adjustable via software
Support ZNET/JenNet-IP/ZigBee-PRO/RF4CE
Support the global license-free ISM 2.4GHz
With built-in 32-bit high-performance and low power MCU
With abundant resources, 512KB FLASH, 32KB RAM
Support 2.0V~3.6V power supply, power supply over 3.3V can guarantee the best performance
Industrial grade standard design, support -40 ~ +85 °C for working over a long time
PCB and IPEX antenna optional, good for secondary and embedded development

Specifications

Chip: jN5169
Frequency: 2.4~2.48GHz
Power: 10dBm
Distance: 500m
Protocol: Zigbee (Recommended)
Antenna: PCB / IPEX
Operating temperature: -40 to +85℃
Dimensions: 16*26mm
Package: SMD

Applications

Smart Home and Industrial Sensors
Wireless toy and remote control
Wireless alarm security system
Building automation solutions
Tire pressure monitoring
Health care products
Wireless audio and wireless earphone
