ESP32-S3-Nano Development Board, Based on ESP32-S3R8, Compatible with Arduino Nano ESP32 - Solder Version

ESP32-S3-Nano Development Board, Based on ESP32-S3R8, Compatible with Arduino Nano ESP32 - Solder Version

ESP32-S3-Nano adopts ESP32-S3R8 as the main controller, compatible with Arduino Nano ESP32, and is suitable for applications such as IoT or MicroPython. Compact in size while with powerful performance, it is applicable for the standalone project.

User Manual / Datasheet / Example Codes Etc.

Features

• Adopting ESP32-S3R8 as the main controller with Xtensa 32-bit LX7 dual-core processor, capable of running at 240 MHz.
• Integrated 512KB SRAM, 384KB ROM, 8MB PSRAM, 16MB Flash memory.
• Integrated 2.4GHz Wi-Fi and Bluetooth LE dual-mode wireless communication, with superior RF performance.
• Supports seamless switching between Arduino and MicroPython programming, offering greater flexibility.
• Compatible with Arduino IoT Cloud, enabling users to monitor and control their projects from anywhere with Arduino Internet of Things (IoT) cloud applications.
• Supports HID (Human Interface Device), allowing simulation of USB human interface devices such as keyboards or mice for more convenient interaction with computers.

Specifications

• MICROCONTROLLER : ESP32-S3R8 (Dual-core 32-bit Xtensa LX7)
• CLOCK FREQUENCY : ESP32-S3R8: 240MHz

• STORAGE : ESP32-S3R8: 384kB ROM, 512kB RAM, 16MB Flash, 8MB PSRAM

• WIRELESS COMMUNICATION : 2.4GHz WiFi + Bluetooth LE

• OPERATING VOLTAGE  : 3.3V
• POWER INPUT : 6~21V

• IO PIN OUTPUT CURRENT : 40mA
• DIGITAL PINS : 14
• ANALOG PINS : 8

Pinout Definition

What's On Board

Dimensions
