LILYGO T-Echo Lite Kit NRF52840 830-945MHz LoRa Development Board with GPS, Bluetooth LE & 1.22inch SP E-Paper Display (K279)

The LILYGO T-Echo Lite Kit is an ultra-low-power LoRa development platform designed for long-range wireless communication, GPS tracking, and off-grid IoT applications. Powered by the Nordic nRF52840 MCU and equipped with an SX1262 LoRa transceiver, Bluetooth 5.0 LE, L76K GPS module, and a 1.22-inch E-Paper display, it is an ideal solution for Meshtastic nodes, asset tracking, environmental monitoring, wearable devices, and battery-powered remote sensing projects. Its compact design, ultra-low sleep current, and solar charging support make it suitable for long-term field deployments.

User Manual / Datasheet / Example Codes Etc.

Features

Nordic nRF52840 ARM Cortex-M4F MCU @ 64MHz
SX1262 LoRa transceiver supporting 830-945MHz frequency band
Built-in Bluetooth 5.0 Low Energy
Integrated L76K GNSS module with GPS, GLONASS, BeiDou, and QZSS support
1.22-inch E-Paper Display (176 × 192 resolution)
Onboard ICM20948 9-axis IMU sensor
Ultra-low power design with deep sleep current as low as 2–10µA
32MB SPI Flash for data logging and firmware storage
USB Type-C interface for programming and power
Solar charging support (5V input)
Compatible with Arduino IDE, PlatformIO, and Meshtastic firmware
Compact portable enclosure suitable for wearable and mobile applications

Specifications

MCU: NRF52840
FLASH: 1MB
RAM: 256kB
Programming Platform: Arduino-IDE, VS Code
Wireless Connectivity: Bluetooth 5, Thread, ANT, Battery Measurement Control: IO 0.31, ADC: IO 0.2
New Features: TCA8418 Keyboard + Audio + Motor
LoRa Transceiver: SX1262, Long Range, Low Power
Support Bands: 400-520MHz, 830-945MHz
Display
1.22 inch SPI E-Paper Display:
Resolution: 176 x 192
Type: GDEM0122T61
GNSS Module
L76K Multi-System Positioning
Support: GPS, GLONASS, BeiDou, QZSS (Internal Optional with/without L76K GPS Function)
Size: 102 x 41 x 22mm
Battery Charging: 5V 500mA

Package Includes

1x LILYGO T-Echo Lite Kit NRF52840 830-945MHz LoRa Development Board with GPS, Bluetooth LE & 1.22inch SP E-Paper Display (K279)
