MAX30100 Pulse Oximeter Heart Rate Sensor Module

MAX30100 Pulse Oximeter Heart Rate Sensor Module

The MAX30100 is integrated pulse oximetry and a heart-rate monitor module. It includes internal LEDs, photodetectors, optical elements, and low-noise electronics with ambient light rejection. The MAX30100 provides a complete system solution to ease the design-in process for mobile and wearable devices.

Features

• VIN – Input voltage (1.8V to 5.5V)
• SCL – IIC-SCL
• SDA – IIC-SDA
• INT – MAX30100INT
• IRD – MAX30100 IR_DRV
• RD – MAX30100 R_DRV
• GND – Ground

Specifications

• Integrated pulse oximetry and heart rate monitor sensor solution.
• Integrated LEDs, Photo Sensor, and High-Performance Analog Front -End
• Complete Pulse Oximeter and Heart-Rate Sensor Solution Simplifies Design
• Measures absorbance of pulsing blood
• I2C interface plus INT pin
• Tiny 5.6mm x 2.8mm x 1.2mm 14-Pin Optically Enhanced System-in-Package
• Ultra-Low-Power Operation Increases Battery Life for Wearable Devices
• Programmable Sample Rate and LED Current for Power Savings
• Ultra-Low Shutdown Current (0.7µA, typ)
• Advanced Functionality Improves Measurement Performance
• High SNR Provides Robust Motion Artifact Resilience
• Integrated Ambient Light Cancellation
• High Sample Rate Capability
• Fast Data Output Capability
