Name: MT9284BS6 1.2MHz, High Efficiency Boost White LED Driver SOT23-6
Brand: AeroSemi
SKU: 03628
Price: 11.80 INR
Availability: OutOfStock

AeroSemi

MT9284BS6 1.2MHz, High Efficiency Boost White LED Driver SOT23-6

Based on 0 reviews. - Write a review

₹11.80

₹10.00 + 18% GST

All Inclusive, Shipping Calculated at Checkout

B2B GST Credit Available

Stock: 0 in Stock
SKU: 03628
Delivery Time
Bulk & B2B RFQ

Buy Now NOTIFY WHEN AVAILABLE

Plan to Buy Later ? Add to Wish List

The MT9284BS6 is a step-up converter designed for driving up to 7 series white LEDs from a single cell Lithium Ion battery. The MT9284 uses current mode, fixed frequency architecture to regulate an LED current, which is measured through an external current sense resistor.

The MT9284BS6 includes under-voltage lockout, current limiting and thermal overload protection preventing damage in the event of an output overload. Optimized operation frequency can meet the requirement of small LC filters value and low operation current with high efficiency. Internal soft start function can reduce the inrush current. Tiny package type provides the best solution for PCB space saving and total BOM cost.

Features

High Efficiency: Up to 90%
1.2MHz Constant Frequency Operation
Integrated internal Power MOSFET
Drives up to 7 Series WLEDs
Soft-start/Dimming with wide Frequency Range
UVLO, Thermal Shutdown
Internal Current limit
Over Voltage Protection
Small LC Filter
Minimize the External Component
<1µA Shutdown Current
SOT23-6 Package

Resources

Technical Datasheet

Applications

Camera Flash White LED
Mobile Phone, Smart Phone LED Backlight
PDA LED Backlight
Digital Still Cameras
Camcorder
