Ebyte NE2-T1M Serial TTL to Ethernet Converter Module - Super Network Port

NE2-T1M is a serial to Ethernet module (also known as "super network port") that realizes serial data ⇌ Ethernet data transmission. The serial to Ethernet module comes with an RJ45 interface and a full network port package. It can meet the networking functions of various TTL level serial devices and MCUs.

Datasheet

Features

RJ45 supports 10 /100M Ethernet interface , cross - connect direct adaptive
The product supports 2-way Socket, each channel supports TCP Server, TCP Client, UDP Server, UDP Client, HTTPC , M QTTC
Supports three configuration methods: configuration tool, web page, and AT command
Server mode supports 5- way Socket connection
Support DHCP function
Supports DNS (domain name resolution) and can customize the domain name resolution server
Supports a variety of Modbus gateways (simple protocol conversion, multi-host mode, storage gateway, configurable gateway , active upload mode )
Supports quick access to Alibaba Cloud, Baidu Cloud, One NET, Huawei Cloud, and version 3.1.1 standard MQTT servers
Support HTTP protocol ( GET/POST request)
Support virtual serial port
Supports disconnection reconnection and timeout restart functions
Supports Keep alive mechanism, which can quickly detect network abnormalities and quickly reconnect
Supports short connection function and can customize short connection interval
All modes support heartbeat package and registration package functions
Support access to external network and local area network
Supports one-click restore to factory settings
Support online upgrade function.

Specifications

Interface: TTL serial port + RJ45
Network Speed: 10M/100M
Working voltage: DC 2.9~3.6V
Packaging: Ethernet port
Product size: 32.5×16.5×17.5mm
Operating Voltage: DC 2.9~3.6V 3.3V power supply is recommended, and the power supply load capacity is recommended to be above 400mA
Working current Peak: [email protected] - Standby: [email protected]
Working mode: TCP Server (default), TCP Client, UDP Server, UDP Client, HTTP Client, MQTT Client
Socket connection: TCP server single link supports 5 client connections
Network protocol: TCP/UDP, MQTT, HTTP, IPv4, DHCP, DNS
IP acquisition method: Static IP (default), DHCP
Serial port baud rate: 600~460800 bps (default 115200)
Working temperature and humidity: -40~+85℃, 5%~95%RH (no condensation)
Storage temperature and humidity: -40~+105℃, 5%~95%RH (no condensation)
