Name: PCIe TO 4-Ch SATA 3.0 Expander, 6Gpbs High-speed SATA Interface, Supports CM4
Brand: WaveShare Electronics
SKU: 22247
Price: 2252.27 INR
Availability: InStock

PCIe TO 4-Ch SATA 3.0 Expander, 6Gpbs High-speed SATA Interface, Supports CM4

WaveShare Electronics

PCIe TO 4-Ch SATA 3.0 Expander, 6Gpbs High-speed SATA Interface, Supports CM4

Based on 0 reviews. - Write a review

₹2,252.27

₹1,908.70 + 18% GST

All Inclusive, Shipping Calculated at Checkout

Assured Cashback of ₹ 19
B2B GST Credit Available

Price in reward points: 1908

Stock: 7 in Stock
SKU: 22247
Delivery Time
Bulk & B2B RFQ

Add to Cart

Buy Now

Plan to Buy Later ? Add to Wish List

Onboard SATA host controller (AHCI) with upstream PCle Gen3 x1 and downstream four SATA Gen3 ports. It's a low latency, low cost and low power AHCI controller. With four SATA ports and cascaded port multipliers, it can enable users to build up various high-speed IO systems, including server, high-capacity system storage or surveillance platforms.

Features

Supports 1-ch PCI Express
Four power-saving modes of L0s/L1/L23/L3
Support L1 sub-state deep power saving mode
Supports SRIS, AER, LTR
Supports SATA LED
Supports NCQ & AHCI SPEC 1.4
Four SATA3.0 (6Gbps) ports
Supports the switching based on the port multiplier commands
Supports SATA Partial/Dormancy power management

Resources

Datasheet and Documentation

Supported Boards Introduction

Working With Official CM4 IO Board

Working With CM4 IoT Industrial Control Base

* for reference only, Compute Module 4 IO Board and Compute Module 4 PoE 4G Board are NOT included.

PCIe To 4-Ch High-Speed SATA 3.0

Compliant With SATA3.0 (SATA Gen3) Standard, Each Channel Up To 6Gbps

Note: the module is PCIe Gen 3 interface but the Raspberry Pi CM4 is PCIe Gen 2 interface, the max speed is 5Gbps.

Speed Test

*the above data are from Waveshare Lab, for reference only.

Flexible Power Supply Option

In Additional To The Power Supply From PCIe Interface, There's Also Power Header For External 5V/12V Input

Power Supply Interfacs For SATA

Supports 5V/12V SATA Hard Disk, Not Support M.2 Interface

High-Performance Controller

Equipped With ASUS Subsidiary Xiangshuo ASMedia ASM1064 Chip
Stable And High-Speed Transmission

LED Indicators

Always On When Inserting The SATA Hard Disk, And Flashes When Reading And Writing Data

Outline Dimensions
