Name: 2-CH Triac HAT for Raspberry Pi, Integrated MCU, UART / I2C
Brand: WaveShare Electronics
SKU: 17852
Price: 2344.66 INR
Availability: OutOfStock

2-CH Triac HAT for Raspberry Pi, Integrated MCU, UART / I2C

WaveShare Electronics

2-CH Triac HAT for Raspberry Pi, Integrated MCU, UART / I2C

Raspberry Pi Store

Based on 0 reviews. - Write a review

₹2,344.66

₹1,987.00 + 18% GST

All Inclusive, Shipping Calculated at Checkout

Assured Cashback of ₹ 20
B2B GST Credit Available

Stock: 0 in Stock
SKU: 17852
Delivery Time
Bulk & B2B RFQ

Buy Now NOTIFY WHEN AVAILABLE

Plan to Buy Later ? Add to Wish List

Dual Channels Bidirectional Triac HAT for Raspberry Pi, Integrated MCU, Commands Control, UART / I2C.

Features

STM32F0 MCU controller, requires minimal Raspberry Pi resource, UART / I2C communication
RC snubber circuit, protect the triac from power fluctuation
Up to 4400W output power, under ideal heat dissipation condition
Optocoupler isolation, preventing interference from the high voltage circuit
Indicator for easy checking the status of triac
Reserved UART and I2C interface, for working with other host control boards
Data rate: up to 921.6kbps for UART，up to 1024kbps for I2C
Comes with development resources and manual (examples in C and Python)

Resources

User Guide

Specifications

AC voltage： 100~600V
AC current： 0~20A
Dimensions：65 × 56.5 (mm)
Working voltage：3.3V/5V
Interfaces：UART/I2C
Controller：STM32F030
UART data rate：1200 ~ 921600bps
I2C data rate：≤1Mbps

Onboard Peripherals

BTA24-600 high power bidirectional triac
MOC3021S photocoupler, the triac driver
LTV-824S AC photocoupler
RC snubber circuit
LM358DR OP amplifier
STM32F030F4P6 main controller
RT9193-33PB power chip
Output indicator
20A blow fuse

Applications

Standard Raspberry Pi 40PIN GPIO header
MCU control interface, for use with other host control boards like Arduino
AC input
AC output
Data bus selection
A: use Raspberry Pi I2C bus
B: use Raspberry Pi UART bus
Mode selection
A: I2C mode
B: UART mode
