Name: Waveshare SIM7600G-H 4G HAT (B) for Raspberry Pi, LTE Cat-4 4G / 3G / 2G Support, GNSS Positioning, Global Band
Brand: WaveShare Electronics
SKU: 19485
Price: 6199.00 INR
Availability: OutOfStock

Waveshare SIM7600G-H 4G HAT (B) for Raspberry Pi, LTE Cat-4 4G / 3G / 2G Support, GNSS Positioning, Global Band

WaveShare Electronics

Waveshare SIM7600G-H 4G HAT (B) for Raspberry Pi, LTE Cat-4 4G / 3G / 2G Support, GNSS Positioning, Global Band

Raspberry Pi Store

This product qualifies for Free Surface Shipping !

All orders with value above 1999+GST are eligible for free delivery in Surface mode. (Not applicable for B2B offline orders)

Based on 0 reviews. - Write a review

₹6,199.00

₹5,253.39 + 18% GST

All Inclusive, Shipping Calculated at Checkout

Assured Cashback of ₹ 54
B2B GST Credit Available

Stock: 0 in Stock
SKU: 19485
Delivery Time
Bulk & B2B RFQ

Buy Now NOTIFY WHEN AVAILABLE

Plan to Buy Later ? Add to Wish List

Features

Connected via pogo pin or MicroUSB connector
Dedicated pogo pin for Raspberry Pi Zero/Zero W
MicroUSB connector for other Raspberry Pi boards or PC
Incorporates SIM7600G-H global band 4G module, compatible with 2G/3G/4G network with global support
USB HUB connector for other Raspberry Pi boards or PC, providing USB extension and 4G network access
Supports dial-up, telephone call, SMS, TCP, UDP, DTMF, HTTP, FTP, etc.
Supports GPS, BeiDou, Glonass, GALILEO, QZSS, LBS base station positioning
SIM card slot, supports 1.8V/3V SIM card
Onboard audio jack and audio decoder for making telephone call
2x LED indicators, easy to monitor the operating status
Control via AT commands (3GPP TS 27.007, 27.005, and V.25TER command set)
Supports SIM application toolkit: SAT Class 3, GSM 11.14 Release 99, USAT
Comes with development resources and manual (examples for Raspberry Pi)

Specifications

BAND
LTE Cat-4	LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B12/B13/B18/B19/B20/B25/B26/B28/B66 LTE-TDD: B34/B38/B39/B40/B41
3G	UMTS/HSDPA/HSPA+: B1/B2/B4/B5/B6/B8/B19
2G	GSM/GPRS/EDGE: 850/900/1800/1900 MHz
GNSS
Satellite systems	GPS/Beidou/GLONASS/GALILEO/QZSS
Receiver type	16-channel
Receiver type	C/A Code
Sensitivity	-159 dBm (GPS) / -158 dBm (GLONASS) / TBD (BeiDou)
Sensitivity	Cold starts: -148 dBm
Time-To-First-Fix (open air)	Cold starts: <35s
Time-To-First-Fix (open air)	Hot starts: <1s
SMS AND AUDIO
SMS	Supported types: MT, MO, CB, Text, PDU
Audio feature	Supports echo cancellation
Audio feature	Supports noise reduction
OTHER
Power supply	5V
Operating temperature	-30°C ~ 80°C
Storage temperature	-45°C ~ 90°C
Dimensions	65.00 × 32.00mm

Resources

Technical Documentation

Onboard Peripherals

SIM7600G-H
FE1.1S USB HUB chip
NAU8810 audio decoder
MP1482 power chip
RT9193-33 voltage translator
USB HUB input D+/D- pogo pin: for Raspberry Pi Zero/Zero W, MicroUSB connector: for other Raspberry Pi boards or PC
Pogo pin power supply 5V: connects to 5V pin of Zero/Zero W, up to 2A current, GND: connects to GND pin of Zero/Zero W
USB extended ports USB1~USB2: USB-A connectors, USB3: solder pad
SIM card slot supports 1.8V/3V SIM card
3.5mm earphone/mic jack
MAIN antenna connector
AUX auxiliary antenna connector
GNSS antenna connector
Power indicator
Network status indicator
