Name: TTGO T-Call & SIM800C-DS V02 ESP32 WIFI Bluetooth Nano Card Slot SIM800C Module Development Board CH9102F (Q218)
Brand: TTGO
SKU: 02769
Price: 2231.38 INR
Availability: InStock

TTGO

TTGO T-Call & SIM800C-DS V02 ESP32 WIFI Bluetooth Nano Card Slot SIM800C Module Development Board CH9102F (Q218)

Based on 0 reviews. - Write a review

₹2,231.38

₹1,891.00 + 18% GST

All Inclusive, Shipping Calculated at Checkout

Assured Cashback of ₹ 19
B2B GST Credit Available

Stock: 4 in Stock
SKU: 02769
Delivery Time
Bulk & B2B RFQ

Add to Cart

Buy Now

Plan to Buy Later ? Add to Wish List

Hardware Specifications

Chipset: ESPRESSIF-ESP32 240MHz Xtensa® single-/dual-core 32-bit LX6 microprocessor

FLASH:QSPI flash 4MB / PSRAM 8MB

SRAM : 520 kB SRAM

Button：Reset

USB to TTL：CH9102F

Modular interface：UART、SPI、SDIO、I2C、LED PWM、TV PWM、I2S、IRGPIO、capacitor touch sensor、ADC、DACLNA pre-amplifier

On-board clock：40MHz crystal oscillator

Working voltage：2.7V-3.6V

Working current :About 70mA

Sleep current: About 1.1mA

SIM card: Only supports Nano SIM card

Working temperature range: -40℃ ~ +85℃

Size&Weight: 78.83mm x 28.92mm x 8.06mm(11.77g)

Power Supply Specifications

Power Supply: USB 5V/1A

Charging current: 500mA

Battery: 3.7V lithium battery

JST Connector: 2Pin 1.25mm

USB: Type-C

Wi-Fi

Standard: FCC/CE-RED/IC/TELEC/KCC/SRRC/NCC(esp32 chip)

Protocol: 802.11 b/g/n(802.11n，speed up to150Mbps)A-MPDU and A-MSDU polymerization，support 0.4μS Protection interval

Frequency range: 2.4GHz~2.5GHz(2400M~2483.5M)

Transmit Power: 22dBm

Communication distance: 300m

Bluetooth Protocol: meet bluetooth v4.2BR/EDR and BLE standard Radio frequency with -97dBm sensitivity NZIF receiver Class-1,Class-2 & Class-3 emitter AFH Audio frequency CVSD&SBC audio frequency

Software specification

Wi-Fi Mode: Station/SoftAP/SoftAP+Station/P2P

Security mechanism: WPA/WPA2/WPA2-Enterprise/WPS

Encryption Type: AES/RSA/ECC/SHA

Firmware upgrade：UART download/OTA（Through network/host to download and write firmware）

Software Development：Support cloud server development /SDK for user firmware development

Networking protocol：IPv4、IPv6、SSL、TCP/UDP/HTTP/FTP/MQTT

User Configuration：AT + Instruction set, cloud server, android/iOSapp

OS：FreeRTOS

More Information: https://github.com/Xinyuan-LilyGO/LilyGo-T-Call-SIM800
