Ebyte E103-W03 CC3220R 2.4GHz Ultra-low Power Serial Port to WiFi Module SMD

E103-W03 is an ultra-low power serial port to Wi-Fi module, SMD small-volume package, PCB antenna, working in the 2.4~2.484GHz frequency band. The module can use the serial port to send and receive data, lowering the threshold of wireless applications.

The E103-W03 module is developed by Chengdu Ebyte Electronic Technology Co., Ltd. based on TI's CC3220R chip. The module integrates the transparent transmission function, which can be used out of the box and supports the serial port AT command set. Users can use the network access function through the serial port. It is widely used in wearable devices, home automation, home security, personal health care, smart home appliances, accessories and remote controls, automotive, lighting, industrial Internet and other fields.

E103-W03 module supports standard IEEE802.11b/g/n protocol and complete TCP/IP protocol stack, supports STA/AP network role, supports multiple network working modes, supports Smart Config, serial port transparent transmission, power-on transparent transmission and other functions , after a simple configuration, the network access function can be realized very conveniently, minimizing the developer's work and project development time.

Datasheet

Features

Support IEEE802.11 b/g/n standard
Support AP, STA, WIFI Direct 3 working modes
Support WEP/WPA/WPA2 multiple WIFI security authentication methods
Support TCP/UDP/HTTP/MQTT multiple network communication protocols
Support TSL/SSL secure transmission mode
Support up to 4 Socket connections
AP access point supports 4-way STA device connection
Support mDNS, DNS-SD, DHCP network service package
Support WEB page parameter configuration
Support NTP network time acquisition (under the premise of Internet access)
Support disconnection automatic reconnection
Support high-speed transmission, the highest support serial port 3M baud rate transmission
Support multiple power consumption mode switching
Support WIFI idle connection (LDPS)
Support MQTT network protocol (Alibaba Cloud, Baidu Cloud, OneNet)
Support WebSocket connection
Support HTTP Client
Support TCP SERVER, TCP CLIENT, UDP communication mode
Support custom registration package, custom heartbeat package function
Support socket distribution protocol
AT command configuration
Support remote command configuration
Support Smart config fast distribution network
Support transparent multi-channel protocol transmission and broadcast transmission
Support pins to restore default parameters
Support mode bus protocol conversion (RTU and TCP)
Support static IPv4 address allocation
Support scanning nearby AP information

Specifications

IC: CC3220R
Frequency: 2.4GHz
Power: 18dBm
Wi-Fi: 802.11 b/g/n
Communication Interface: UART serial port
Antenna form: PCB Onboard Antenna/IPX Socket
Operating temperature: -40 ~ +85℃
Working humidity: 10% ~ 90%
Storage temperature: -40 ~ +85℃
