4.2inch E-Paper E-Ink Display Module For Raspberry Pi Pico, 400×300 Pixels, Black / White, SPI Interface

This is a 4.2inch e-Paper display module for Raspberry Pi Pico, 400 x 300 pixels, support black, white, and 4 grayscale display, SPI interface.

User Manual / Datasheet / Example Codes Etc.

Features

No backlight, keeps displaying last content for a long time even when power down.
Ultra-low power consumption, basically power is only required for refreshing.
SPI interface, requires minimal IO pins.
Onboard voltage translator, compatible with 3.3V / 5V MCUs.
2 x user buttons for easy interacting.

Specifications

Size: 4.2 inch
Outline dimensions (bare screen): 90.1mm × 77.0mm × 1.18mm
Outline dimensions (driver board): 93.5mm × 78.5mm
Display size: 84.8mm x 63.6mm
Operating voltage: 3.3V/5V
Communication interface: SPI
Pitch: 0.212 x 0.212
Resolution: 400 x 300
Display color: Black, White
Greyscale: 4
Full refresh: 4s
Refreshing power: 26.4mW(typ.)
Sleep current: <0.01uA (almost 0)

Package Includes

1x Pico-ePaper-4.2
1x PH2.0 8PIN wire 20cm
1x Standoff pack

Raspberry Pi Pico Header Compatibility

Onboard SPI Control Interface

VCC : 3.3V/5V
GND : Ground
DIN : SPI MOSI pin
SCK : SPI SCK pin
CS : SPI chip selection, low active
DC : Data / Command selection (high for data, low for command)
RST : External reset, low active
BUSY : Busy status output

Onboard Voltage Translator

Pinout Definition

Dimensions
