Name: 7Semi EC200U LTE 4G Cat-1 GNSS Mini Industrial Modem USB-C (MPN: CM-10132)
Brand: 7Semi
SKU: 08490
Price: 2342.00 INR
Availability: OutOfStock

7Semi EC200U LTE 4G Cat-1 GNSS Mini Industrial Modem USB-C (MPN: CM-10132)

New

7Semi

7Semi EC200U LTE 4G Cat-1 GNSS Mini Industrial Modem USB-C (MPN: CM-10132)

Based on 0 reviews. - Write a review

₹2,342.00

₹1,984.75 + 18% GST

All Inclusive, Shipping Calculated at Checkout

Assured Cashback of ₹ 20
B2B GST Credit Available

Price in reward points: 1984

Stock: 0 in Stock
SKU: 08490
Delivery Time
Bulk & B2B RFQ

Buy Now NOTIFY WHEN AVAILABLE

Plan to Buy Later ? Add to Wish List

7Semi EC200U LTE 4G Cat-1 GNSS Mini Industrial Modem USB-C

The best option for your wireless connection needs is the 7Semi EC200U-CN LTE 4G GPS GNSS Mini Modem with USB-C connector! This modem has incredible features that are guaranteed to impress, all thanks to the Quectel EC200U-CN module at its heart. For your convenience and flexibility, it supports 5V USB power supply and 5 external power supply, UART communication, and USB communication and power supply. In addition to supporting nano sim, the mini modem is simple to use and configure.

All of the frequency bands supported by the 7Semi EC200U-CN LTE 4G GPS GNSS Mini Modem are B1/B3/B5/B8 LTE-FDD and B34/B38/B39/B40/B41 LTE-TDD. You won't ever have to worry about losing connection or being unable to precisely track your assets thanks to the GSM 900 MHz/1800 MHz and GNSS capabilities, which include GPS, GLONASS, BeiDou, Galileo, and QZSS.

Furthermore, you can be certain that you're receiving the strongest signal possible thanks to the extra benefit of an FPC antenna. The 7Semi EC200U-CN LTE 4G GNSS Mini Modem with FPC Antenna is the perfect choice whether you work in the transportation sector, industrial automation, or any other area that needs dependable communication and tracking.

The EC200U-CN LTE Cat 1 wireless communication module, developed by Quectel, is used by the 7Semi LTE 4G GPS Mini Modem. QuecOpen, a module from the EC200U series, allows data connections over GSM/GPRS, LTE-FDD, and LTE-TDD networks. It also supports GNSS (GPS, GLONASS, BeiDou, Galileo, and QZSS). The flexible features of the EC200U series QuecOpen module are very advantageous for M2M applications.

The 7Semi 4G LTE antenna is compatible with BLE and LoRa/RF and covers 700–2700 MHz, making it ideal for applications that demand a wide frequency range. This antenna has an IPEX (u.FL equivalent) connector and measures 52 x 24 mm. Its 3M adhesive backing makes it simple to attach to your project.

Datasheet

Board Features

Power Supply: 5V USB / 5V External Supply
Frequency Bands

LTE-FDD B1/B3/B5/B8
LTE-TDD B34/B38/B39/B40/B41
GSM 900 MHz/1800 MHz
GNSS: GPS, GLONASS, BeiDou, Galileo, QZSS

Antenna Features

Frequency range: 700-2700Mhz
Gain: 8dBi internal antenna
VSWR: <=1.8
Input impedance: 50 Ohm
Material: Radiator FPC
Antenna Size: 52x24mm
Cable type: 1.13 coaxial cable
Connector style: IPEX (u.FL equivalent)
Polarization: Vertical
Power: 30w
Mounting: 3M sticker

Package Includes

1x 7Semi EC200U LTE 4G Cat-1 GNSS Mini Industrial Modem USB-C
