ESP32-S3 Development Board, 32-Bit LX7 Dual-Core Processor, Integrates GC9A01 Display Driver Chip, With 1.28inch IPS Round LCD, 240×240 Resolution, Supports WiFi/Bluetooth

ESP32-S3-LCD-1.28 is a low-cost, high-performance MCU board designed by Waveshare, tiny size, with onboard 1.28inch LCD display, Li-ion battery recharge manager, 6-axis sensor (3-axis accelerometer and 3-axis gyroscope), and so on, which makes it easy for you to develop and integrate it into products quickly.

User Manual / Datasheet / Example Codes Etc.

Features

Equipped with Xtensa® 32-bit LX7 dual-core processor, up to 240MHz main frequency
Supports 2.4GHz Wi-Fi (802.11 b/g/n) and Bluetooth® 5 (BLE), with onboard antenna
Built in 512KB of SRAM and 384KB ROM, with onboard 2MB PSRAM and an external 16MB Flash memory
Type-C connector, keeps it up to date, easier to use
Onboard 1.28inch LCD display, round IPS panel, 240×240 resolution, 65K color
Onboard QMI8658 6-axis IMU (3-axis accelerometer and 3-axis gyroscope) for detecting motion gesture
Onboard 3.7V lithium battery recharge/discharge header and GPIO headers
Supports flexible clock, module power supply independent setting, and other controls to realize low power consumption in different scenarios
Integrated with USB serial port full-speed controller, GPIO pins allow flexibly configuring pin functions

Onboard 1.28inch LCD Screen

Round IPS Panel, 240×240 Resolution, 65K Color

30 × Multi-Function GPIO Pins

What's On Board

1. ESP32-S3R2

The SoC with WiFi and Bluetooth, up to 240MHz operating frequency, with onboard 2MB PSRAM

2. W25Q128JVSIQ

16MB NOR-Flash

3. QMI8658

6-axis IMU includes a 3-axis gyroscope and a 3-axis accelerometer.

4. ME6217C33M5G

800mA output, low dropout, high rejection rate

5. CH343P

USB to UART chip

6. ETA6096

high-efficiency Lithium battery recharge manager

7. 1.27mm pitch headers

Adapting multiple GPIO pins

8. BOOT button

Press it before resetting to enter download mode

9. RESET button

10. MX1.25 battery header

MX1.25 2P connector, for 3.7V Lithium battery, supports charging and discharging

11. USB Type-C connector

USB to UART, for programming and log printing

12. 2.4GHz ceramic antenna

Dimensions
